Standard Refrigerated Air Dryer (Refrigerated Compressed Air Drying Equipment)

OROIN RAX Light Duty Series

Air-Cooled Type RAX3J ~ 55G / Water-Cooled Type RAX55G-W

※ Compressed air processing conditions: compressed air inlet pressure (gauge pressure): 0.69MPa inlet air temperature for models RAX3J~37G: 35℃, models RAX55G,55G-W: 40℃ outlet air dew point at atmospheric pressure: -17℃ dew point under pressure: 10℃ ambient temperature: 32℃

※ Please contact us for guaranteed performance specifications

※ Processing air capacity is calculated based on compressor intake conditions (atmospheric pressure, 32℃、75%.)

※ RAX55G-W Cooling water flow rate is for 60Hz operation.

※ 1 In case power source fluctuation is within±5% 2 ~ 40 ℃ for ±10%. ● RAX15 ~ 55G-W come standard equipped with control terminals for remote operation (no-voltage switch) ● Chinese pressure vessel code compliant model available upon request. Please inquire for further information.

※ Please contact ORION regarding custom built models of specifications outside the ranges listed above.

Standard Refrigerated Air Dryer (Refrigerated Compressed Air Drying Equipment)

ORION RAX Heavy Duty Series

Air-Cooled RAX75F ~ 380F-E / Water-Cooled RAX75F-W ~ 450F-WE

● RAX75F ~ 190F-W

※ Air processing conditions: compressed air inlet pressure (gauge pressure): 0.69MPa inlet air temperature:40℃ outlet air dew point: -17℃ pressure dew point: 10℃ ambient temperature: 32℃

Please contact us for guaranteed performance specifications. Heavy duty models have had performance specifications confirmed with a substitute load (inspection under low pressure air)

※ Processing air capacity is calculated based on compressor intake conditions (atmospheric pressure, 32℃ 75%)

※ Cooling water flow rate is for 60Hz operation. ● Standard equipped with remote control terminals (no-voltage), operation signal terminals (no-voltage), alarm signal terminals (no-voltage.) ● Air inlet/outlet connection companion flanges not included. ● Flange: JIS10K FF. ● RAX75F(F-W) ~ 190F(F-W) models equipped with suspension eyebolts. ● Chinese pressure vessel code compliant model available upon request. Please inquire for further information.

※ Please contact ORION regarding custom built models of specifications outside the ranges listed above.

● RAX240F ~ 450F-WE

Air processing conditions: compressed air inlet pressure (gauge pressure): 0.69MPa inlet air temperature: 40℃ outlet air dew point: -17℃ pressure dew point: 10℃ ambient temperature: 32℃

Please contact us for guaranteed performance specifications. Heavy duty models have had performance specifications confirmed with a substitute load (inspection under low pressure air)

※ Processing air capacity is calculated based on compressor intake conditions (atmospheric pressure, 32℃ 75%.)

※ Cooling water flow rate is for 60Hz operation. ● Standard equipped with remote control terminals (no-voltage), operation signal terminals (no-voltage), alarm signal terminals (no-voltage.) ● Remote operation and stop signals be controlled by momentary switches. ● RAX  F-E・ F-WE models have 2 power modes (50% and 100%) For power outages of 0.2 seconds and less, operation will resume automatically. The dryer will automatically switch between refrigeration compressors 1 and 2 There are separate alarm monitors. Terminals for 2 types of alarm are provided: main alarm and preliminary caution. ● An air-cooled model, RAX450F-E is available as a built to order item. ● Alarm equipped electric drain trap is available by special order. ● Air inlet/outlet connection companion flanges not included. ● Flange: JIS 10K FF. ● Chinese pressure vessel code compliant model available upon request. Please inquire for further information.

※ Please contact ORION regarding custom built models of specifications outside the ranges listed above.

※ RAX240F ~ 450F-WE are subject to JBA 2nd class pressure vessel regulation.

※ Models subject to JBA 2nd class pressure vessel regulation are built-to-order models.
